Inverter Heat Pump Split Air Conditioner
High Efficiency, Low GWP R290
Cooling & Heating
9,000 / 12,000 / 18,000 BTU
Energy Class A+++ with BOOST
Self-cleaning with Sterilization
Smart, Eco-Friendly Water Heating & Heating Solution for Residential and Commercial Use
Product Highlights
The Monobloc Heat Pump integrates a complete heating and hot water solution in a single outdoor unit, eliminating the need for an indoor compressor module. With eco-friendly refrigerants (R290 or R32), these units deliver high seasonal efficiencies and strong heating performance even in cold climates, providing outlet water temperatures of up to 75 °C (R290 models) or 60 °C (R32 models). incorporate smart defrost logic for reliable frost-prone operation, provide optional integrated hydraulic modules and buffer tanks for fast installation, and support Wi-Fi control with OTA updates for remote monitoring.
BreezelessTM with Twinflap design: 7,928 micro-holes diffuse airflow softly and evenly, avoiding direct cold drafts
Ultra-fast cooling & heating: Inverter compressor delivers rapid response, ramping up to 65 Hz in just 6 seconds.
Ultra-quiet operation: Indoor unit runs as low as 20 dB, ensuring quiet comfort.
Eco & Night Modes: Intelligent settings optimize energy use for efficiency and savings.
Wi-Fi Smart Control: Remote access via MideaAIR app, Alexa, or Google Home.
iClean self-cleaning: Prevents dust, bacteria, and odors, ensuring healthier airflow.
Advanced multi-layer filtration: Silver ion, HEPA, and ColdCatalyst filters remove allergens, VOCs, and fine dust.
Golden Fin heat exchanger: Corrosion-resistant coating enhances durability and extends system lifespan.
Product Overview
Technical Specifications
| Model (R290) | MMHP-15D1 | MMHP-22D1 | MMHP-22D3 |
|---|---|---|---|
| Cooling Capacity (BTU/h, kW) | 9,000 BTU (2.64 kW) | 12,000 BTU (3.52 kW) | 18,000 BTU (5.28 kW) |
| Heating Capacity (BTU/h, kW) | ~10,000 BTU (2.93 kW) | ~13,000 BTU (3.81 kW) | ~19,000 BTU (5.57 kW) |
| SEER (cooling, seasonal W/W) | 7.4 (EU A++ class) | 7.0 (EU A++ class) | 7.0 (EU A++ class) |
| EER (cooling, nominal W/W) | 3.6 | 3.23 | 3.4 |
| COP (heating, nominal W/W) | 3.8 | 3.71 | 3.76 |
| Refrigerant Type | R32 (eco-friendly HFC) | R32 (eco-friendly HFC) | R32 (eco-friendly HFC) |
| Compressor Type | Rotary (DC inverter) | Rotary (DC inverter) | Rotary (DC inverter) |
| Power Supply (V ~ / Ph / Hz) | 220–240 V~ / 1Ph / 50 Hz | 220–240 V~ / 1Ph / 50 Hz | 220–240 V~ / 1Ph / 50 Hz |
| Power Input (cooling/heating, W) | 739 / 771 W (nominal) | 1,089 / 1,027 W (nominal) | 1,550 / 1,682 W (nominal) |
| Operating Current (cool/heat, A) | 3.2 / 3.3 A | 4.7 / 4.5 A | 6.8 / 7.3 A |
| Indoor Unit (W×D×H, mm; weight) | 726 × 210 × 291 mm; 8.0 kg | 835 × 208 × 295 mm; 8.7 kg | 969 × 241 × 320 mm; 11.2 kg |
| Outdoor Unit (W×D×H, mm; weight) | 720 × 270 × 495 mm; 23.5 kg | 720 × 270 × 495 mm; 23.7 kg | 874 × 330 × 554 mm; 33.5 kg |
| Indoor Noise Level (dB(A)) | 20 – 37 dB(A) (quiet to high fan) | 21 – 37 dB(A) | 20 – 37 dB(A) |
| Outdoor Noise Level (dB(A)) | 55.5 dB(A) (max) | 55 dB(A) (max) | 57 dB(A) (max) |
| Airflow (Indoor) (m³/h) | 330 – 520 m³/h (low to high) | 350 – 530 m³/h | 500 – 800 m³/h |
| Operating Temp Range (outdoor) | Cooling: -15°C ~ 50°C; Heating: -15°C ~ 24°C | Cooling: -15°C ~ 50°C; Heating: -15°C ~ 24°C | Cooling: -15°C ~ 50°C; Heating: -15°C ~ 24°C |
| Smart Features | Built-in Wi-Fi (remote app control) | Built-in Wi-Fi (remote app control) | Built-in Wi-Fi (remote app control) |
| Other Key Technologies |
|
||
Key Features
Application Scenarios
- Villas & apartments.
- Offices, classrooms, and meeting halls
- Hotels and hospitality facilities
- Retail shops and restaurants
- Healthcare centers and small clinics
Technical Specifications
- Cooling range: 2.6 – 10.5 kW.
- Heating range: 2.8 – 11.0 kW
- SEER up to 8.5 / SCOP up to 4.6
- Cooling -15°C ~ 50°C | Heating -25°C ~ 30°C
- Wi-Fi + Smart Home compatibility
